Low switching losses
VCE(sat) with positive temperature coefficient
Square RBSOA
Low inductance case
Fast & soft reverse recovery anti-parallel FWD
Isolated copper baseplate using DBC technology
Welding Machines
Inverters
Induction Heating
Plasma Cutting Machines
| TYPE | VCES Volts | VGES Volts | IC Amps | VCE(SAT) Volts | (EON+EOFF) mJ | TJ | Ptot Watts | Circuit | Package | Technology |
| LVG40H12E4L | 1200V | ± 20 | 40A | 2.10V | 5.2mJ | 150℃ | 380 | 4 Pack | 48mm | NPT |
| LVG50H12E4L | 1200V | ± 20 | 50A | 2.80V | 5.8mJ | 150℃ | 401 | 4 Pack | NPT | |
| LVG75H12E4L | 1200V | ± 20 | 75A | 2.80V | 11.8mJ | 150℃ | 595 | 4 Pack | NPT |
